** Obsolete Product ** , SQ75, 400 W, 32 V, CAN Direct
Replacement Options
80360001 80360004
Replace 1 obsolete product(s) by 1 new product(s).
Replacement for IP54
View product
Media & Documents
- Product info
-
Product key features, technical specs, technical schemas and more.
- Brochure SQ75 Smart Motor EN (PDF)
- Brochure SQ75 Smart Motor FR (PDF)
- Brochure SQ75 Smart Motor IT (PDF)
- Brochure SQ75 Smart Motor DE (PDF)
- Brochure SQ75 Smart Motor ES (PDF)
- Market Applications - Access Control EN (PDF)
- Market Applications - Railway Brochure EN (PDF)
- Motors & Gearmotors Overview EN (PDF)
- Motors & Gearmotors Overview FR (PDF)
- Motors & Gearmotors Overview DE (PDF)
- Guides
- User Guides, Notices and more.
- Certifications
- RoHS Approval, EU Declaration, ATEX Conformity and more.
- Media Kit
-
High Resolution pictures, Arguments and more.
- Product Presentation EN (HTML)
- Range Presentation EN (HTML)
- 3D Drawing (STP)
- 2D Drawing (PDF)
- Product Picture Low Res. (PNG)
- Product Picture High Res. (PNG)
- DC Brush & Brushless Motors Web Banner (PNG)
- CROUZET Product Overview EN (PDF)
- CROUZET Product Overview FR (PDF)
- CROUZET Product Overview DE (PDF)
- CROUZET Product Overview IT (PDF)
- CROUZET Product Overview ZH (PDF)
Distributors Stock Check
Checking stock arround the globe
Product Description
The new SQ75 DCmind Brushless motors have an integrated drive and CANopen communication bus for Motion Control applications up to 600 W nominal power and up to 6 Nm peak torque. More power, accurate precision, as well as enhanced safety and security features to secure your application.
Crouzet DCmind Brushless Motors range features high-performance Brushless DC motors having output power ratings from 77 to 600 W and a choice of three integrated electronic control systems as well as CANopen communication bus capability.
Crouzet DCmind Brushless motors are easy to integrate and use. They combine superb power density, integrated electronics and numerous functions for speed, torque and positioning control. Additionally, when equipped, they can be used as slaves in CANopen networks, making them ideal for applications in service robotics, industry, valves, pumps, access control and the energy sector.
Technical Specifications
| N/A | |
| Bearing | Ball bearing |
| Breakdown torque ratio | N/A |
| Construction type | N/A |
| Cooling method | Air |
| Degree of protection (IP) | IP67 |
| Degree of protection (NEMA) | N/A |
| Duty cycle | N/A |
| Frame size acc. IEC | 75 |
| Full-load efficiency | 85 |
| Insulation class acc. IEC | Other |
| Intrinsic safety (IS) | N/A |
| Material housing | N/A |
| Model | Direct current motor |
| Nominal torque | 1.3 |
| Number of phases | 3 |
| Number of poles | 8 |
| Operation temperature | -30°C / +70°C |
| Output power anti-condensation heater | N/A |
| Power factor | N/A |
| Rated current | 14.4 |
| Rated frequency | N/A |
| Rated performance at rated frequency | 400 |
| Rated rotational speed at rated frequency | 2955 |
| Rated voltage | 32 |
| Shaft end type | Key |
| Starting current ratio | N/A |
| Starting torque ratio | N/A |
| Suitable for frequency control | N/A |
| Vacuum pressure impregnation (VPI) | N/A |
| Voltage anti-condensation heater | N/A |
| Voltage type | DC |
| With anti-condensation | 1 |
| With positive temperature coefficient resistor (PTC) | N/A |
| With resistance temperature detector (RTD) | N/A |
